1將機體后蓋打開，油箱的油面應保持在油標的中心線以上，以防油泵吸空，加油時應用120目過濾網濾去新油中的雜質。
1, open the rear lid of the body. The oil surface of the tank should be kept above the centerline of the oil mark, so as to prevent the oil pump from emptied. When using oil, 120 mesh filter is used to filter the impurities in the new oil.
2調試：當安裝完畢后，要針對某型材做如下順序調整。
2 debugging: when the installation is finished, the following sequence adjustment should be made for a profile.
3將溢流閥松開，按下液壓?jiǎn)?dòng)按鈕，觀察電機旋向（從上方觀察電機應順時針?lè)较蛐D(zhuǎn)）。將連動開關撥到關位，踩下腳踏閥調整溢流閥，順時針?lè)较驍Q動溢流閥調整手輪，系統工作壓力提高，反之系統壓力降低。
3 release the overflow valve, press the hydraulic start button, observe the motor rotation (from above the motor should be clockwise rotation of the motor). The connecting switch is switched to the shut position, the pedal valve is adjusted, the relief valve is adjusted, the relief valve is adjusted in a clockwise direction, the working wheel is adjusted, and the working pressure of the system is improved, otherwise, the system pressure is reduced.

4將連動開關撥到開位，將控制面板上的定位延時調為2S~3S。退刀延時出廠前已調整好，一般情況下，無須調整。特殊情況下，可打開電器箱，將時間繼電器加以調整。

4 switches the switch to the open position and switches the positioning delay on the control panel to 2S~3S. The time delay of the retreating tool has been adjusted before the factory. In general, it is not necessary to adjust. In special cases, the electric box can be opened and the time relay is adjusted.
5將裝好角碼的型材置于壓緊定位塊前方，45度接縫處的外角點對準壓緊定位塊90度內角的頂端。按型材高度調整主定位塊高度，使之與型材相適應。組角刀具的高度與型材連接的角碼高度相適應，當型材內側凸筋特殊時應更換主定位塊，使之能深入到筋間空腔內，不至于頂?shù)浇钌?，因此主定位塊設計成活連接，以便用戶自行按型材配作各種定位塊。
Section is tightly positioning block will be installed in front of the 5 corner, the top 45 of the joint angle at the point of 90 degrees angle pressing positioning block. The height of the main block is adjusted according to the height of the profile, so that it can be adapted to the profile. Height and section angle tool connecting bracket corresponds to the height, when the medial rib profiles should replace the main special positioning block, which can go deep into the ribs in the cavity, so as not to the top bar, so the main positioning block design survival connection, so that users with various profiles according to self positioning block.
6主定位塊前后位置的調整：踩下腳踏閥使主定位塊運行到前極限位置，然后旋轉定位缸調整手輪，終使主定位塊達“圖二”所示位置。
6, the adjustment of the front and rear position of the main positioning block: step on the foot valve to make the main block run to the front limit position, then rotate the positioning cylinder to adjust the handwheel, and finally make the main location block reach the position shown in Figure two.
7壓緊定位塊的調整：松開壓緊螺釘，對壓緊定位塊高低位置進行調整，使其相對于主定位塊之溝槽上下對稱。然后對其前后位置進行調整：首先將要組角的型材裝上角碼，放于主定位塊前的定位位置，再松開壓緊螺釘，調整壓緊定位塊的前后位置，終使型材正確定位。完畢后將型材拿出。
The adjustment of the 7 compression positioning block: loosening and pressing the screw, adjusting the position of the pressing position block, so that it is symmetrical to the groove of the main positioning block. And then to adjust its position before and after: first will be installed on the corner section angle, put in the position of the main location in front of the block, then loosen the clamping screw, adjust the pressing positioning block before and after the position, finally make the correct positioning of profile. After the end, the profile is taken out.
8組角刀位置的調整：松開壓緊螺釘，使兩組角刀的上下位置對稱分布于壓緊定位塊的上下兩邊，并不超過型材邊緣，將螺釘壓緊。旋轉滑板調整手輪，對組角刀前后位置調整。調整到組角刀的行程時，其位置應達要求。
8 groups of corner cutter position adjustment: loosening the compression screw, so that the upper and lower positions of the two groups of corner knives are symmetrically distributed on the upper and lower sides of the clamping blocks, which do not exceed the edge of the profiles, and screw the screws tightly. The rotary slide plate adjusts the hand wheel and adjusts the position of the corner knife. To adjust the maximum stroke angle knife, its position should be required.
